Количество в упаковке : 1
Important: For best results, the intersection of the alternating flute directions (APMX_2) should be positioned in the middle of the workpiece height
Coated tools available on request
For user guide, see pages
Important: For best results, the intersection of the alternating flute directions (APMX_2) should be positioned in the middle of the workpiece height
Coated tools available on request
For user guide, see pages
| DC | DCONMS | APMX | APMX_2 | OAL | NOF | FHA | Shank | fz (min) | fz (max) | CCMS | COATP | CSP | GRDMFG | HAND | KAPR | LU | RE | RMPX° | ZEFF | NFMetals | CutEdMat | Coating | GICAT | GIREM | giic |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 8.00 | 8.00 | 16.00 | 6.60 | 63.00 | 6 | 30.0 | C | 0.02 | 0.06 | ZYL01F8000h$06~ | ~ | 0~ | IC02 ~ | R~ | 90.0~ | -~ | 0.00~ | 5.0~ | 6~ | Non Ferrous Metals~ | Carbide~ | Uncoated ~ | 5622870 | 1 |
Данные о продукции
| Сплав и Vc | IC02 |
