Количество в упаковке : 1
Solid tools are suitable for PICCO-N / PICCO ACE-N type holders only
DIN13 , ISO 68-1, ISO 965 (1&2) - Internal tolerance: 6H
ANSI/ASME B1.1 - Internal tolerance: 2B
Solid tools are suitable for PICCO-N / PICCO ACE-N type holders only
DIN13 , ISO 68-1, ISO 965 (1&2) - Internal tolerance: 6H
ANSI/ASME B1.1 - Internal tolerance: 2B
TP  | DCONMS | HC | CF | PDX | WF | a | LU | OAL | DMIN | TPN | TPX | TPIN | TPIX | THFT | TTP | CBMD | CSP | GRDMFG | HAND | ApplMat | StaSteel | CastIron | HardMa | SupTit | CutEdMat | Coating | GICAT | GIREM | giic |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0.500~ | 5.05 | 0.27 | 0.06 | 0.4 | 1.90 | 4.40 | 14.0 | 36.00 | 5.00 | 0.500 | 0.750 | 36.00 | 48.00 | VP60~ | INT~ | FT~ | 1~ | IC908 ~ | R~ | Steel~ | Stainless Steel~ | Cast Iron~ | Hard Materials~ | Superalloys and titanium~ | Carbide~ | TiAlN ~ | 3360855 | 1 |
Данные о продукции
| Сплав и Vc | IC908 |
